1MT0013 Series Dust Explosion-proof Grade 3 Energy Efficiency(China) Low Voltage Three-phase Asynchronous Motor

Rated output：0.55 ~ 315 kW

Frame size：80 ~ 355

Voltage and Frequency：Support multiple voltage and frequency

Cooling method：IC411

Frame-proof marking：Ex tb IIIC T130 ℃ Db

Protect degree：IP65

Insulation class： F

Re-greasing device：FS280 and above motor as standard

Ambient temperature：-15 ℃ ~ 40 ℃

Site altitude above sea level：Not exceed 1000m

Efficiency Grade：IE3

Beide series high efficiency dust explosion-proof three-phase asynchronous motor is totally enclosed, self-fan cooled high efficiency motor. The products meet the requirements of the GB18613-2020 efficiency of energy efficiency grade 3. The series products introduce Siemens design technology with excellent performance, safe and reliable to use, low vibration, low noise, and meet environmental protection requirements. Its production equipment adopt advanced CNC machine tool equipment, citing Siemens advanced insulation structure design and manufacturing process, use high quality cold rolled silicon steel sheet and high quality bearing with strict quality control. Beide dust explosion-proof motor can be used for food or forage machine, wood machine, flour machine or storage, as well metal, chemicals, synthetic resin, agricultural products and all kinds of combustible dust places such as fiber, fuel and so on. Detailed types of dust refer to "dust characteristics example," but this series motors are not suitable for gas or underground coal mine with combustible dust and coal mine ground device with electrical equipment, also can’t be used in place with explosive dust and spontaneous combustion substances (e.g. phosphorus powder) but can burn without oxygen from the atmosphere.
